2 Inch Schedule 80 Carbon Steel Pipe
2 Inch Schedule 80 Carbon Steel Pipe
Built for tough industrial environments, this 2-inch Schedule 80 carbon steel pipe delivers heavy-wall durability for high-pressure setups, water lines, compressed air systems, and custom fabrication. We supply it cut to your exact length, with options for different material grades, surface finishes, and end preparations to match your project specifications.
- Mill Test Certificate Provided
- Strict Quality Inspection
- Custom Sizes Available
- On-Time Global Delivery
The 2-inch Schedule 80 carbon steel tubing is built with a heavy wall for systems that need extra thickness beyond standard piping. Following ASME B36.10M standards, it features a 2-inch nominal size, a 60.3 mm outside diameter, and a 5.54 mm wall thickness. This heavier wall gives it a larger metal cross-section compared to lighter pipes of the same nominal size, making it ideal for high-pressure or demanding applications
Key Features
Standard Schedule 80 Dimensions: Built to spec with a 2-inch nominal size, a 60.3 mm outside diameter, and a 5.54 mm wall thickness.
Heavy-Wall Build: The solid 5.54 mm wall gives you the extra strength needed for tough industrial runs and fabrication work.
Carbon Steel Grades: Sourced in standard carbon steel grades to match your project requirements.
Custom Fabrication: Ready to be cut, welded, threaded, beveled, or grooved depending on how you’re connecting it.
Surface Finishes: Available in black, oiled, bare, painted, or galvanized finishes based on your specs.
Documentation: Material Test Certificates and inspection reports can be provided upon request.
2 Inch Schedule 80 Carbon Steel Pipe Specifications
| Item | Available Range |
|---|---|
| Product | 2 Inch Schedule 80 Carbon Steel Pipe |
| Nominal Size | 2 Inch / DN50 |
| Outside Diameter | 60.3 mm |
| Schedule | Schedule 80 |
| Wall Thickness | 5.54 mm |
| Material | Carbon Steel / Q195 / Q235 / Q355 / ASTM A53 Grade A / Grade B |
| Standard | ASME B36.10M / ASTM A53 / ASTM A106 / API 5L |
| Production Process | ERW / Seamless |
| Length | 3 – 12 m / Customized |
| Surface | Black / Oiled / Bare / Painted / Galvanized |
| End | Plain End / Threaded End / Beveled End / Grooved End |
| Processing | Cutting / Threading / Beveling / Grooving / Drilling / Welding |
| Tolerance | According to Standard / Customized |
| Application | Industrial Piping / Water Lines / Air Lines / Equipment Connections / Structural Fabrication |
| Packing | Steel Straps / Bundles / Waterproof Packing / Standard Export Seaworthy Packing |
| MOQ | Based on Quantity, Length & Specification |
| Inspection | MTC / Dimension Inspection / Third-Party Inspection Available |
| Customization | Length / Material Grade / Surface / End Treatment / Processing Available |
Applications
Industrial Piping Systems: Perfect for process piping, utility lines, and fluid transfer in manufacturing plants and workshops.
Water Supply & Utility Lines: Ideal for industrial water supply, pump connections, and circulation systems that call for a thicker wall.
Compressed Air Systems: Handles compressed air lines connecting compressors, storage tanks, valves, and pneumatic equipment.
Steam & Service Piping: Suitable for low- to medium-pressure service lines carrying steam, hot water, and other utilities (based on your design standards).
Equipment Connections: Great for plumbing pumps, valves, tanks, filters, and heat exchangers that require 2-inch Schedule 80 dimensions.
Steel Fabrication & Supports: Frequently used for building pipe supports, structural frames, guards, and handrails where extra strength is a must.
FAQ
1. What are the dimensions of 2 Inch Schedule 80 Carbon Steel Pipe?
The nominal size is 2 inches (DN50), with an outside diameter of 60.3 mm and a wall thickness of 5.54 mm according to ASME B36.10M dimensions.
2. What is 2 Inch Schedule 80 Carbon Steel Pipe used for?
It is commonly used for industrial piping, water and utility lines, compressed air systems, equipment connections, service piping and pipe supports.
3. Can the pipe be supplied in customized lengths?
Yes. Standard lengths and customized fixed lengths can be supplied according to project requirements and order quantity.
4. Can 2 Inch Schedule 80 Carbon Steel Pipe be welded or threaded?
Yes. The pipe can be supplied with plain, threaded, beveled or grooved ends, and cutting, threading, beveling and other processing can be arranged as required.
5. What material grades are available?
Common carbon steel grades can be supplied according to the required product standard, such as ASTM A53 or ASTM A106 grades where applicable. Q195, Q235 and Q355 can also be supplied for suitable applications.
6. Can you provide inspection and material certificates?
Yes. Material Test Certificates (MTC), dimensional inspection and third-party inspection can be provided according to the agreed specification and order requirements.
